| SUITBLE FOR | ||||
|---|---|---|---|---|
| STEAM | WATER | OIL | AIR | |
Gas Valve Butterfly Handle
Salient Features
- Design Standard Is 14846 PN 1.0
- Bolted Bonnet, inside Screw, Non-Rising Stem.
- Rigid And Sturdy Design.
- HandWheel Operated.
- Flange Ends As Per is 1538.
Technical Data
- Design & manufactureing Std.:Ansi B16.34 / API 00
- Testing & Inspection Std:API 598
- Face to Face:AS PER ANSI B 16.10
- END Connection:ANSI B16.5
| MATERIAL LIST | ||||
|---|---|---|---|---|
| P.NO | Name Of Part | Material of Constuction | Specifications | Qty. |
| 1 | Body | Cast Iron | IS 210 GR.200 | 1 |
| 2 | Sear Ring | Broze | IS 318 GR.LTBA | 4 |
| 3 | Wedge | Cast Iron | IS 210 GR.200 | 1 |
| 4 | Stem | Broze | IS 318 GR.LTBA | 1 |
| 5 | Gasket | Rubber | IS 318 GR.TYPE B | 1 |
| 6 | Bonnet | Cast Iron | IS 210 GR.12 CR.12 | 1 |
| 7 | Stem | stanless Steel | IS 6603 GR.12 CR.12 | 1 |
| 8 | Gasket | Rubber | IS 318 GR.TYPE B | 1 |
| 9 | Stuffing Box | Cast Iron | IS 210 GR.12 CR.200 | 1 |
| 10 | Gtand Packing | Hemp & Jute | IS 5414 | 1 |
| 11 | Gland Flange | Cast Iron | IS 210 GR.200 | 1 |
| 12 | HandWheel | Cast Iron | IS 210 GR.200 | 4 |
| 13 | Washer | Carbon | --- | 1 |
| 14 | Bolt | Carbon | IS 1363 PART ! CLASS 4.6 | 1 |
| 15 | Bolt & Nut | Carbon | IS 1363 PART ! CLASS 4.6 | AS REQD. |
| 16 | Stud & Bolt | Carbon | IS 1363 PART ! CLASS 4.6 | 2 |
| 17 | Nut | Carbon | IS 1363 PART ! CLASS 4.6 | AS REQD. |
| SIZE / DIMENSIONS | |||||
|---|---|---|---|---|---|
| Size(mm) | A+1.5 | B | OC | OD+5.0 | E(MAX.) |
| 40 | |||||
| 50 | 178+2 | 16+2 | 165(+1 5/-1.0) | 225 | 365 |
| 65 | 190+2 | 16+2 | 185(+1 5/-1.0) | 225 | 380 |
| 80 | 203+2 | 21 | 200+4.5 | 225 | 425 |
| 100 | 229+2 | 22+3 | 220+4.5 | 320 | 470 |
| 125 | 254+2 | 22.5+3 | 250+4.5 | 320 | 485 |
| 150 | 267+2 | 23+3 | 285(+5.5/2.5) | 320 | 595 |
| 200 | 292+2 | 24.5+3 | 340(+5.5/2.5) | 360 | 725 |
| 250 | 330+2 | 26+3 | 3985(+5.5/2.5) | 400 | 835 |
| 300 | 356+2 | 27.5+3 | 445(+5.5/-2.5) | 400 | 910 |
| 350 | 381+2 | 29+3 | 505(+6.5/-3.0) | 500 | 1020 |
| 400 | 406+2 | 30+3 | 565(+6.5/-3.0) | 640 | 1110 |
| 450 | 432+2 | 31.5+3 | 615(+6.5/-3.0) | 720 | 1200 |
| 500 | |||||
| 600 | 508+2 | 36+3 | 720(+6.5/-3.0) | 720 | 1500 |
